Key Specifications

Active or Passive

Active

System Type

Full-Range

Configuration

2-way

System Continuous Power

350 W

System Peak Power

700 W

Max SPL @ 1m

128 dB

Freq Range (-10 dB)

50 Hz - 20 kHz

Freq Response (+/-3 dB)

55 Hz - 20 kHz

Bi-amp Mode Switch

No

Bluetooth

Yes

IP Certification

None

Driver Brand

Wharfedale Pro

LF Driver Size

12"

LF Voice Coil Size

2"

LF Rated Impedance

4 Ω

LF Power (RE:AES2-2012)

250 W

HF Driver Type

Compression Driver

HF Voice Coil Size

1.75"

HF Diaphragm Material

Titanium

HF Exit Size

1"

HF Power (RE:AES2-2012)

40 W

HF Rated Impedance

8 Ω

HF Nominal Coverage (H x V)

90° x 60°

Preset Library

No

Input Connector

2 x XLR, 2 x RCA, 1 x 6.3mm Jack, USB, BT

Waveguide Type

Constant Directivity

Enclosure Material

ABS

Grille Material and Finish

Steel Black

Finish

Black Polypropylene

Handles

3

Deployment

Flying, Ground, Pole

Pole Mount

35 mm With Lock Screw

Brackets Included

No

Rigging

Yes

M8

4

Sensitivity 2.83v / 1m

96 dB

System Rated Impedance

n/a

Crossover Frequency

HI PASS 2.5 kHz, LOW PASS 2.5 kHz

Recommended HPF = BW 18 dB/OCT.

50 Hz

Transformer (T)

No

Amplifier design

HF Amp Class AB : LF Amp Class D

EQ Type

+/-12 dB Gain for bass and treble

Active loudspeaker Input Impedance

47 KΩ Balanced

Link Connector

pin XLR

Max input level

5 V

Line output

Pin XLR

Main Power

100 V - 120 V and 220 V - 240 V

Power Supply

SMPS

Unpacked - Height (mm)

603

Unpacked - Width Front (mm)

377

Unpacked - Width Rear (mm)

217

Unpacked - Depth (mm)

347

Packed - Height (mm)

666

Packed - Width Front (mm)

430

Packed - Width Rear (mm)

430

Packed - Depth (mm)

408

Weight - Nett (kg)

15

Weight - Gross (kg)

17
