WHARFEDALE TOURUS-AX15-MBT
WHARFEDALE TOURUS-AX15-MBT
|
Key Specifications |
|
|
Active or Passive |
Active |
|
System Type |
Full-Range |
|
Configuration |
2-way |
|
System Continuous Power |
450 W |
|
System Peak Power |
900 W |
|
Max SPL @ 1m |
130 dB |
|
Freq Range (-10 dB) |
45 Hz - 20 kHz |
|
Freq Response (+/-3 dB) |
50 Hz - 20 kHz |
|
Bi-amp Mode Switch |
No |
|
Bluetooth |
Yes |
|
IP Certification |
None |
|
Driver Brand |
Wharfedale Pro |
|
LF Driver Size |
15" |
|
LF Voice Coil Size |
2" |
|
LF Rated Impedance |
4 Ω |
|
LF Power (RE:AES2-2012) |
350 W |
|
HF Driver Type |
Compression Driver |
|
HF Voice Coil Size |
1.75" |
|
HF Diaphragm Material |
Titanium |
|
HF Exit Size |
1" |
|
HF Power (RE:AES2-2012) |
40 W |
|
HF Rated Impedance |
8 Ω |
|
HF Nominal Coverage (H x V) |
90° x 60° |
|
Preset Library |
No |
|
Input Connector |
2 x XLR, 2 x RCA, 1 x 6.3mm Jack, USB, BT |
|
Waveguide Type |
Constant Directivity |
|
Enclosure Material |
ABS |
|
Grille Material and Finish |
Steel Black |
|
Finish |
Black Polypropylene |
|
Handles |
3 |
|
Deployment |
Flying, Ground, Pole |
|
Pole Mount |
35 mm With Lock Screw |
|
Brackets Included |
No |
|
Rigging |
Yes |
|
M8 |
4 |
|
Sensitivity 2.83v / 1m |
97 dB |
|
System Rated Impedance |
n/a |
|
Crossover Frequency |
HI PASS 2.4 kHz, LOW PASS 2.4 kHz |
|
Recommended HPF = BW 18 dB/OCT. |
45 Hz |
|
Transformer (T) |
No |
|
Amplifier design |
HF Amp Class AB : LF Amp Class D |
|
EQ Type |
+/-12 dB Gain for bass and treble |
|
Active loudspeaker Input Impedance |
47 KΩ Balanced |
|
Link Connector |
pin XLR |
|
Max input level |
5 V |
|
Line output |
Pin XLR |
|
Main Power |
100 V - 120 V and 220 V - 240 V |
|
Power Supply |
SMPS |
|
Unpacked - Height (mm) |
693 |
|
Unpacked - Width Front (mm) |
455 |
|
Unpacked - Width Rear (mm) |
262 |
|
Unpacked - Depth (mm) |
402 |
|
Packed - Height (mm) |
762 |
|
Packed - Width Front (mm) |
508 |
|
Packed - Width Rear (mm) |
508 |
|
Packed - Depth (mm) |
425 |
|
Weight - Nett (kg) |
19.2 |
|
Weight - Gross (kg) |
22 |
