Key Specifications

Product Model

TPS 12MA

System Type

2-Way Bi-Amp Active Monitor Speaker

Power Rating

• Program: 830W
• Peak: 1660W

Acoustic Performance

Transducers

• LF: 12" (305mm) / 2" Voice Coil
• HF: 1" Driver / 1" Voice Coil

Frequency Response

60Hz - 20KHz (-6dB)

Max SPL (@ 1m)

121dB Max

Horn Coverage (H x V)

70° x 70°

Connectivity & Processing

Input Connectors

• Input: XLR/Jack Combo
• Link: XLR Male

Presets

Switchable: FOH (Front of House) / Monitor

Controls

Volume, Ground Lift, Power/Clip Indicators

Physical Construction

Enclosure

Trapezoidal MDF Wood, Black Paint finish

Protection

Analog Limiter (Low-High)

Dimensions / Weight

48.8 x 44.2 x 46.9 cm | 15.54 kg
