Key Specifications

Maximum Sampling Rate

192 kHz / 24-Bit

Number of Microphone Inputs

1

Analog Audio I/O

1x Combo XLR-1/4" TRS Mic/Line/Hi-Z Input
1x 1/4" TRS Headphone Output
2x 1/4" TRS Monitor Output

Digital Audio I/O

No

Host Connection

1x USB-B (Class-Compliant)

Power Requirements

USB Bus Power

General

Display

1x Color Multi-Segment LED Meter (Backlit)

Built-In DSP

No

Maximum Sampling Rate

192 kHz / 24-Bit

Number of Microphone Inputs

1

Built-In Microphone

No

Input Level Adjustment

1x Knob

Signal Processing

Pad

No

High-Pass Filter

No

Solo/Mute

No

Connectivity

Analog Audio I/O

1x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line/Hi-Z Input (Front Panel)
1x 1/4" TRS Unbalanced Headphone Output (Front Panel)
2x 1/4" TRS Balanced Monitor Output

Phantom Power

48 V, Selectable On/Off (Applied to All Inputs)

Digital Audio I/O

No

Host Connection / USB

1x USB-B (Class-Compliant)

Host Connection Protocol

USB 2.0

USB (Non-Host)

No

Sync I/O

No

Network I/O

No

MIDI I/O

No

Expansion Slots

No

Wireless

No

Performance

Frequency Response

Combo XLR-1/4" Mic, Line, Hi-Z Inputs: 20 Hz to 20 kHz

Maximum Input Level

Combo XLR-1/4" Mic Inputs: +9 dBu (Balanced)
Combo XLR-1/4" Line Inputs: +20 dBu (Balanced)
Combo XLR-1/4" Hi-Z Inputs: +10 dBu (Unbalanced)

Headphone Output Power

1/4": 114 mW into 500 Ohms (Unbalanced)

Impedance

Combo XLR-1/4" Mic Inputs: 3.5 Kilohms (Balanced, Mic Level)
Combo XLR-1/4" Line Inputs: 15 Kilohms (Balanced, Line Level)
Combo XLR-1/4" Hi-Z Inputs: 1 Megohm (Unbalanced)
Combo XLR-1/4" Headphone Outputs: < 10 Ohms (Unbalanced)

Dynamic Range

Combo XLR-1/4" Analog/Mic/Line/Hi-Z Inputs: 107 dBu (A-Weighted)
1/4" Analog/Monitor Outputs: 107 dB (A-Weighted)

THD+N

Combo XLR-1/4" Mic/Line Inputs: < 0.0011% (20 Hz to 20 kHz, at -1 dBFS)
Combo XLR-1/4" Hi-Z Inputs: 107 dB (A-Weighted)
1/4" Monitor Outputs: < 0.0012% (20 Hz to 20 kHz, at -1 dBFS)

EIN

Combo XLR-1/4" Mic Inputs: < -120 dB

Digital Audio

Sample Rates

44.1 to 192 kHz

Sample Rate Conversion

No

Bit Depths

16 / 24-Bit (AD/DA Conversion, Recording, Playback)

Latency

Zero-Latency Direct Monitoring

Sync Sources

No

Audio Storage & Playback

Media/Memory Card Slot

No

Compatibility

OS Compatibility

Windows 10 or Later / macOS

Mobile Device Compatibility

Android Smartphone
Android Tablet
iPad
iPhone

Required Hardware

USB-A Port

Power

Power Requirements

USB Bus Power

Physical

Certifications

CE

Dimensions

4.95 x 3.6 x 1.81" / 12.57 x 9.1 x 4.6 cm

Weight

1.1 lb / 0.5 kg

Packaging Info

Package Weight

1.73 lb

Box Dimensions (L × W × H)

7.3 x 7 x 3.6"
