TOA TS-680 AS
TOA TS-680 AS
|
Key Specifications |
|
|
Power & Capacity |
|
|
Power Source |
220 - 240 V AC, 50/60 Hz |
|
Rated Output |
36 V DC, 480 mA |
|
Power Consumption |
20 W |
|
Connectable Units |
Maximum 24 units (Delegate/Chairman) |
|
Audio I/O & Processing |
|
|
Selectable Input |
MIC: -60 dB, 600 Ω | AUX: -20 dB, 10 kΩ |
|
Recording Output |
-20 dB, 10 kΩ, Unbalanced RCA |
|
Automatic Mic-Off |
Selectable: OFF or 30 seconds |
|
Conference Control Functions |
|
|
Speaker Restriction |
Simultaneous units usable: 0 to 3 |
|
Priority Control |
Single-tone chime via Chairman's priority key |
|
Physical Specifications |
|
|
Dimensions (W x H x D) |
420 × 96.1 × 222.5 mm (16.54 × 3.78 × 8.76") |
|
Weight |
2.7 kg (5.95 lb) |
|
Finish |
Black Aluminum Panel / Steel Case (30% gloss) |
|
Operating Humidity |
90 %RH or less (no condensation) |
TOA TS-680 AS Accessories
- No accessories available.
