Key Specifications

Power & Audio Output

Power Source

36 V DC, ≤ 30 mA (via Central Unit TS-680)

Internal Speaker

130 Ω, 200 mW (Adjustable Volume)

Headphone/Rec Out

32 Ω (HP) / 10 kΩ (-20 dB), Mini Jack

Microphone Unit (Included Accessory)

Type / Directivity

Electret Condenser / Unidirectional

Frequency Response

100 Hz - 13 kHz

Sensitivity

-37 dB (1 kHz, 0 dB = 1V/Pa)

Length / Weight

518 mm (20.39") / 105 g

Control & Interface

Talk Key

Microphone and Speaker ON/OFF Control

Priority Button

Overrides Delegate units with Chime activation

Volume Control

Rotary dial for Speaker and Headphones

Physical Specifications

Dimensions (W x H x D)

145.3 × 70.7 × 150.5 mm (Base unit)

Weight (Base Unit)

800 g (1.76 lb)

Finish

Black ABS Resin, Painted
