Key Specifications

Power Source

7.4 V DC (BP-900 Battery) or 9 V DC (AD-0910 AC Adapter)

Current Consumption

Max. 270 mA

Battery Life

Approx. 10 Hours (Continuous use)

Infrared Wireless Specs

Wavelength

870 nm (AM: Brightness Modulation)

Carrier Frequencies

Transmission: 7.35 to 9.15 MHz | Reception: 1.95 MHz

Covering Range

7 m (23 ft) Radius

Effective Angles

Vertical: 90° / Horizontal: 120°

Audio & Hardware

Microphone Input

XLR-4-31 (For TS-903 or TS-904 Goosenecks)

Monitor Speaker

8 Ω, 0.2 W (Built-in)

Headphone Output

2 × 3.5 mm Mini Jack (Monaural)

Physical Specs

Operating Temp

0 °C to +40 °C (32 °F to 104 °F)

Priority Function

Yes (Chairperson Priority Speech)
