Key Specifications

Power Source

24 V DC (supplied from the Central Unit)

Current Consumption

Max. 150 mA

Infrared Emitter / Detector

Wavelength

870 nm (AM: Brightness modulation)

Modulation Method

Frequency modulation

Carrier Frequency

Transmission:
Audio Channel 1: 7.35 MHz
Audio Channel 2: 8.10 MHz
Audio Channel 3: 8.55 MHz
Audio Channel 4: 9.15 MHz
Control Channel: 6.45 MHz

Reception:
Base Language Channel: 1.95 MHz
Translation Language Channel: 2.25 MHz

Acceptance Angle

Vertical: 150° (75° + 75°), Horizontal: 360°

Emission Angle

Vertical: 150° (75° + 75°), Horizontal: 360°

Communication Area

Approx. 6 - 7 m radius from the point underneath the unit
(Ceiling height: 2.5 - 4.5 m)

Connection Terminal

BNC Jack

LED Indicator

Power

Environmental

Operating Temperature

0°C to +40°C (32°F to 104°F)

Operating Humidity

90% RH or less (non-condensing)

Physical Properties

Finish

Dome: PC resin, visible light cut filter
Base: ABS resin, black

Dimensions

Ø120 × 71.3 (H) mm (4.72 × 2.81 in)

Weight

230 g (0.51 lb) (unit only)

Accessories

Included Accessories

Mounting bracket ×1
Stand mounting bracket ×1
Stand mounting bracket attaching screws ×3
Thread Adapter (U5/16 - NS5/8) ×1

Optional Accessory

Microphone stand (mounting thread size must be U5/16 or NS5/8)
