TXO-234 MKII
TXO-234 MKII
TOPP PRO
Regular price
₱8,820.00 VAT INC.
Regular price
Sale price
₱8,820.00
Unit price
per
UNIT: PIECE/S
Product Code: SKU:TOPP-TXO234M-CHN-369
Key Features
Authorized Dealer
Certified Quality Products
After-Sales Support
Secure Payments
TOPP PRO TXO-234 MKII
TOPP PRO TXO-234 MKII
|
Key Specifications |
|
|
Product Model |
TXO-234 MKII |
|
Device Type |
2/3/4-Way Active Crossover |
|
Filter Type |
Linkwitz-Riley, 24dB/Octave |
|
Dynamic Range |
>106dB (Unweighted) |
|
Audio Connectivity |
|
|
Input Connectors |
XLR (Balanced & RF Filtered) |
|
Output Connectors |
XLR (Electronically Servo-Balanced) |
|
Max Input Level |
+22 dBu |
|
Performance & Processing |
|
|
Frequency Response |
5 Hz to 90 kHz (+0/-0.3dB) |
|
Crossover Frequencies |
44 Hz to 930 Hz (x10 switch for 9.3 kHz) |
|
Low Output Delay |
Adjustable 0 to 2 msec |
|
Special Functions |
CD Horn EQ, Limiter, Phase Invert, LF Sum |
|
Physical & Power |
|
|
Dimensions (WxDxH) |
483 x 194.5 x 44 mm (1U Rack) |
|
Net Weight |
3 kg (6.61 lbs) |
|
Power Consumption |
< 17 W |
