Key Specifications

Active or Passive

Active

System Type

Full-Range

Configuration

2-way

System Continuous Power

720 W

System Peak Power

1440 W

Max SPL @ 1m

129 dB

Frequency Response (+/-3 dB)

55 Hz – 20 kHz

Frequency Range (-10 dB)

50 Hz – 20 kHz

Bluetooth

Yes

IP Certification

IP54

Drivers & Components

Driver Brand

Wharfedale Pro

LF Driver Size

12"

LF Voice Coil Size

2.5"

LF Rated Impedance

4 Ω

LF Power (RE:AES2-2012)

250 W

HF Driver Type

Compression Driver

HF Voice Coil Size

1.75"

HF Diaphragm Material

Titanium

HF Exit Size

1"

HF Power (RE:AES2-2012)

40 W

HF Rated Impedance

8 Ω

HF Nominal Coverage (H x V)

100° x 80°

Crossover Frequency

2.1 kHz

Connectivity & DSP

Preset Library

No

Preset List

Flat / Monitor / Bass / Punch (with FIR)

DSP Controls

Flat / Monitor / Bass / Punch (with FIR)

Input Connector

2 x XLR, 2 x 6.3mm Jack, Bluetooth

Active Loudspeaker Input Impedance

20 KΩ

Link Connector

Pin XLR

Input Sensitivity

775 mV (0 dBu)

Max Input Level

4 V

Line Output

Pin XLR

Physical & Installation

Waveguide Type

Hybrid Symmetry Horn

Enclosure Material

Polypropylene

Grille Material and Finish

Steel Black

Finish

Black Polypropylene

Handles

4

Deployment

Flying, Pole, Wall Mount, Ground

Pole Mount

35 mm With Lock Screw

Brackets Included

No

Rigging

Yes

M8 Points

9

Power

Amplifier Design

Class D

Main Power

100-120 V~ / 200-240 V~, 50/60 Hz

Power Supply

SMPS

Dimensions & Weight

Unpacked Dimensions (H x W Front x W Rear x D)

558 x 344 x 245 x 340 mm

Packed Dimensions (H x W Front x W Rear x D)

645 x 425 x 425 x 419 mm

Weight - Net

16.2 kg

Weight - Gross

18.9 kg
