Key Specifications

Acoustical Specifications

Frequency Response (-3 dB)

65 Hz–18 kHz

Max SPL @ 1 m

113 dB / 119 dB (Peak)

Dispersion (H × V)

90° × 60°

Transducers

Compression Driver

1 × 1.3" HF

Woofer

1 × 10" LF

Input / Output Section

Input Connectors

2 × NL4

Sensitivity (1 W @ 1 m)

95 dB

Power Section

Total Power

250 W (RMS); 500 W (Music); 1000 W (Peak)

Nominal Impedance

8 Ω

Physical Specifications

Cabinet / Case Material

Polypropylene Injection Moulding

Hardware

8 × M8 Hanging Points, SMART Pole Mount System

Handles

Two Side, One Rear

Grille

Powder Coated Grille

Color

Black

Size

Dimensions (W × D × H)

321 × 321 × 464 mm (12.6 × 12.6 × 18.3 in)

Package Dimensions (W × D × H)

375 × 355 × 535 mm (14.8 × 14 × 21.1 in)

Weight

Net Weight

10 kg (22 lb)

Gross Weight

12 kg (26.5 lb)
