Key Specifications

Acoustical Specifications

Frequency Response (-3 dB)

50 Hz–18 kHz

Max SPL @ 1 m

114 dB / 120 dB (Peak)

Dispersion (H × V)

100° × 55°

Transducers

Compression Driver

1 × 1.7" HF

Woofer

1 × 12" LF

Input / Output Section

Input Connectors

2 × NL4

Sensitivity (1 W @ 1 m)

97 dB

Power Section

Total Power

300 W (RMS); 600 W (Music); 1200 W (Peak)

Nominal Impedance

8 Ω

Physical Specifications

Cabinet / Case Material

Polypropylene Injection Moulding

Hardware

8 × M8 Hanging Points, SMART Pole Mount System

Handles

Two Side, One Rear

Grille

Powder Coated Grille

Color

Black

Size

Dimensions (W × D × H)

415 × 382 × 620 mm (16.3 × 15 × 24.4 in)

Package Dimensions (W × D × H)

465 × 435 × 680 mm (18.3 × 17.1 × 26.8 in)

Weight

Net Weight

18 kg (39.7 lb)

Gross Weight

20 kg (44.1 lb)
