Key Specifications

Acoustical Specifications

Frequency Response (-3 dB)

50 Hz–18 kHz

Max SPL @ 1 m

112 dB / 118 dB (Peak)

Dispersion (H × V)

100° × 55°

Transducers

Compression Driver

1 × 1.7" HF

Woofer

1 × 12" LF

Input / Output Section

Input Signal

Balanced 20 kΩ, Unbalanced 10 kΩ

Input Connectors

2 × XLR

Power Section

Total Power

100 W HF, 300 W LF (RMS)

Nominal Impedance

8 Ω

Cooling

Internal horn vibration auxiliary air cooling + convective radiation outside the back plate

Voltage Range

AC 220V–240V~, 50/60Hz (or AC 110V–120V~, 50/60Hz)

Physical Specifications

Cabinet / Case Material

Polypropylene Injection Moulding

Hardware

8 × M8 Hanging Points, SMART Pole Mount System

Handles

Two Side, One Rear

Grille

Powder Coated Grille

Color

Black

Size

Dimensions (W × D × H)

415 × 382 × 620 mm (16.3 × 15 × 24.4 in)

Package Dimensions (W × D × H)

465 × 435 × 680 mm (18.3 × 17.1 × 26.8 in)

Weight

Net Weight

23 kg (50.7 lb)

Gross Weight

25.2 kg (55.6 lb)
