XVIVE U35C
XVIVE U35C
|
Key Specifications |
|
|
Wireless Technology |
Digital 5.8 GHz |
|
Diversity |
Yes, True Diversity |
|
Max Operating Range |
100' / 30.5 m |
|
Receiver Type |
1x Plug-In (XLR 3-Pin) |
|
Number of Audio Channels |
1 |
|
Included Transmitters |
1x Plug-On Microphone |
|
Microphone Type |
No Microphone Included |
|
Included Charging Case |
No |
|
System |
|
|
Wireless Technology |
Digital 5.8 GHz |
|
Diversity |
Yes, True Diversity |
|
RF Frequency Band |
5730 to 5844 MHz |
|
Number of RF Channel Frequencies |
6 |
|
Max Operating Range |
100' / 30.5 m |
|
Max Transmitters per Band |
1 |
|
Dynamic Range |
110 dB |
|
Latency |
5 ms |
|
Encryption |
No |
|
Built-In Recorder |
No |
|
Timecode Support |
No |
|
Mobile App Compatible |
No |
|
Receiver |
|
|
Receiver Type |
1x Plug-In (XLR 3-Pin) |
|
Mounting Options |
XLR Plug-In (with Included Hardware) |
|
Antenna |
2x Internal 1/4 Wave Sleeve Dipole |
|
Number of Audio Channels |
1 |
|
Audio I/O |
1x XLR 3-Pin Balanced Output |
|
Network I/O |
No |
|
USB/Lightning Connectivity |
1x USB-C Female (Charging) |
|
Frequency Response |
20 Hz to 20 kHz |
|
Display |
No |
|
Power Requirements |
Battery |
|
Transmitters |
|
|
Included Transmitters |
1x Plug-On Microphone |
|
RF Output Power |
25 mW |
|
Antenna |
Internal 1/4 Wave Sleeve Dipole |
|
Input Level |
Microphone |
|
Audio I/O |
1x XLR 3-Pin Male Input |
|
Bias/Plug-In & Phantom Power |
No Bias/Plug-In Power |
|
USB I/O |
1x USB-C (Charging) |
|
Muting |
Off/On Switch |
|
Frequency Response |
20 Hz to 20 kHz ±3 dB |
|
Sync Method |
Manual |
|
Display |
No |
|
Microphones |
|
|
Microphone Type |
No Microphone Included |
|
Power |
|
|
Receiver Battery Type |
1x Built-In Rechargeable - 860 mAh |
|
Receiver Battery Life |
5 Hours |
|
Transmitter Battery Type |
1x Built-In Rechargeable - 1000 mAh |
|
Transmitter Battery Life |
5 Hours |
|
Battery Charging Time |
2.5 Hours |
|
Included Charging Case |
No |
|
Charging Case |
|
|
AC/DC Power Adapter |
No |
|
Physical |
|
|
Environmental Resistance |
No |
|
Housing |
Metal, Plastic |
|
Dimensions |
Receiver: 3.2 × 1.2 × 1.1" / 81 × 31 × 29 mm |
|
Weight |
Receiver: 3.2 oz / 92 g |
|
Packaging Info |
|
|
Package Weight |
0.685 lb |
|
Box Dimensions (L × W × H) |
6.3 × 4.7 × 1.5" |
