Key Specifications

Acoustical Specifications

Frequency Response (-3 dB)

65 Hz–18 kHz

Max SPL @ 1 m

104 dB / 110 dB (Peak)

Dispersion (H × V)

90° × 60°

Transducers

Compression Driver

1 × 1.3" HF

Woofer

1 × 8" LF

Input / Output Section

Input Signal

Balanced 20 kΩ, Unbalanced 10 kΩ

Input Connectors

2 × XLR

Power Section

Total Power

150 W (RMS); 300 W (Music); 600 W (Peak)

Nominal Impedance

8 Ω

Cooling

Internal horn vibration auxiliary air cooling + convective radiation outside the back plate

Voltage Range

AC 220V–240V~, 50/60Hz (or AC 110V–120V~, 50/60Hz)

Physical Specifications

Cabinet / Case Material

Polypropylene Injection Moulding

Hardware

8 × M8 Hanging Points, SMART Pole Mount System

Handles

Two Side, One Rear

Grille

Powder Coated Grille

Color

Black

Size

Dimensions (W × D × H)

277 × 257 × 400 mm (10.9 × 10.1 × 15.7 in)

Package Dimensions (W × D × H)

595 × 310 × 460 mm (23.4 × 12.2 × 18.1 in)

Weight

Net Weight

8.6 kg (19 lb)

Gross Weight

18.6 kg (41 lb)
