Key Specifications

Max I/O Capacity

12x Input / 4x Output

Number of Analog Input Channels

12 (12 Mono / 0 Stereo)

Number of Mic Preamps

8

Number of Analog Output Channels

4

Faders & Level Adjustment

2 Knob

Built-In Effects

No

Analog Inputs

1x Stereo RCA Coaxial Stereo Line Input
2x Combo XLR-1/4" TRS Mic/Line/Hi-Z Input
2x Combo XLR-1/4" TRS Mic/Line Input
4x XLR 3-Pin Mic Input

Analog Outputs

2x 1/4" Headphone Output
2x XLR Aux Send
2x XLR Main Output
2x 1/4" Main Output

Digital I/O

1x RJ45 (Control)

USB I/O

1x USB-A (Audio Playback)

Wireless

Wi-Fi

Rack Mountable

Yes

Mixer

Max I/O Capacity

12x Input / 4x Output

Number of Analog Input Channels

12 (12 Mono / 0 Stereo)

Number of Mic Preamps

8

Number of Analog Output Channels

4

Mix Routing

1x Subgroup

Groups

1x Subgroup
1x Mute Group

Presets

No

Faders & Level Adjustment

2 Knob

Signal Processing

Gain / Trim Range

Line/Mic: -40 dB to +50 dB
Main: +23 dBu

Dynamic Processing

Compressor

EQ

4-Band EQ

EQ Parameters

Notch: ±20 dB at 20 Hz to 22 kHz, 0.5 to 15 Q

Filters

High-Pass: 20 Hz to 1 kHz

Solo / Mute

Solo, Mute per Input Channel

Built-In Effects

No

Audio Delay

No

Automatic Mic Mixing

Yes

Digital Audio

Bit Depth

16 / 24 / 32-Bit

Performance

Frequency Response

20 Hz to 20 kHz

Headphone Output Power

500 mW

I/O Impedance

Mic Input: 10 Kilohms
Line Input: 10 Kilohms
Hi-Z Input: 250 Kilohms
Output: 100 Ohms

Signal Generator

No

Connectivity

Analog Inputs

1x Stereo RCA Coaxial Stereo Line Input
2x Combo XLR-1/4" TRS Mic/Line/Hi-Z Input
2x Combo XLR-1/4" TRS Mic/Line Input
4x XLR 3-Pin Mic Input

Analog Outputs

2x 1/4" TRS Headphone Output
2x XLR 3-Pin Balanced Aux Send
2x XLR Main Output
2x 1/4" Main Output

Phantom Power

+48 V

Digital I/O

1x RJ45 (Control)

MIDI I/O

No

USB I/O

1x USB-A (Audio Playback)

Wireless

Wi-Fi

External Display I/O

No

Recording

Max Multitrack Recording

12 Tracks

Compatibility

OS Compatibility

Computer: Windows / macOS / Linux
Mobile: Android / iPadOS

Mobile Device Compatibility

iPad
Android Tablet

Power

Input Power

88 to 265 VAC, 50 / 60 Hz

Physical

Rack Mountable

Yes

Rackmount Size

4 U

Dimensions

3.3 x 7 x 12.6" / 85 x 177 x 320 mm

Weight

5 lb / 2.3 kg

Packaging Info

Package Weight

7.21 lb

Box Dimensions (L × W × H)

18 x 10.65 x 5.75"
