BLACKMAGICDESIGN Ultimatte 12 HD Mini
BLACKMAGICDESIGN Ultimatte 12 HD Mini
|
Key Specifications |
|
|
Video I/O & Standards |
|
|
Video Inputs |
2x HDMI Input | 1x BNC (3G-SDI) Input |
|
Video Outputs |
1x HDMI Output | 2x BNC (3G-SDI) Output |
|
Monitor Output |
1x BNC (3G-SDI) Monitor Output |
|
SDI Compliance |
SD/HD/3G-SDI Rates (up to 1080p60) |
|
General & Control |
|
|
Application Type |
Real-Time Compositing Processor (Chroma Keyer) |
|
Compatibility |
Blackmagic Design Ultimatte Smart Remote 4 |
|
USB I/O / Connector Type |
1x USB-C 3.0 / 3.1/3.2 Gen 1 Female Input |
|
Physical & Power |
|
|
Rackmountable / Mounting |
1x Rack Unit (One-third rack width) |
|
Power Source / Input Power |
AC Input | 100 to 240 VAC, 50 / 60 Hz |
|
Power Consumption |
12 W |
|
Dimensions / Weight |
6.96 x 5.51 x 1.74" / 17.68 x 14 x 4.42 cm | 2.56 lb / 1.16 kg |
