Key Specifications

Compatibility

Blackmagic Design Ultimatte 12 8K
Blackmagic Design Ultimatte 12 4K
Blackmagic Design Ultimatte 12 HD
Blackmagic Design Ultimatte 12 HD Mini

Controls

8 × Rotary Knobs
1 × File Clear Button
8 × Unit ID Buttons
5 × Preset Buttons

Display

Panel Type

LCD

Display Size

10.1"

Native Resolution

1280 × 800

Touchscreen

Yes

Inputs / Outputs

USB I/O

2 × USB-C 2.0 Female Input
1 × USB-C 3.0 / 3.1 / 3.2 Gen 1 Female Input

Video Output

1 × HDMI Output

Network I/O

2 × RJ45 Input/Output

Supported Resolution

1920 × 1080p

Wireless

Wireless Connectivity

Wi-Fi

Power

Power Source

AC Input

AC Input Power

100 to 240 VAC, 50 / 60 Hz

Power Consumption

24 W

Physical Specifications

Color

Black

Operating Conditions

32 to 95°F (0 to 35°C), up to 90% Humidity

Storage Conditions

-4 to 140°F (-20 to 60°C), up to 90% Humidity

Dimensions

431.8 × 175.3 × 104.1 mm (17 × 6.9 × 4.1")

Weight

4.21 kg (9.29 lb)

Packaging Information

Package Weight

12.53 lb

Box Dimensions (L × W × H)

20.4 × 12.8 × 8.3"
