Key Specifications

Video Resolution

BNC Input

8/10/12-Bit 4:4:4 / 4:2:2 RGB and YUV

Supported BNC Resolutions

2048 × 1080p up to 60 fps
1920 × 1080p up to 60 fps

HDMI Input

8/10/12-Bit 4:4:4 / 4:2:2 RGB and YUV

Supported HDMI Resolution

1920 × 1080p up to 60 fps

Embedded Audio

HDMI / SDI

Standards

HDR Support

No

Broadcast System Compatibility

NTSC, PAL

Hardware

Operating System Compatibility

Windows
macOS
Linux

Power

Power Input

1 × USB-C Input

Environmental

Operating Conditions

32 to 104°F (0 to 40°C), up to 90% Humidity

Storage Conditions

-4 to 113°F (-20 to 45°C), up to 90% Humidity

Physical Specifications

Dimensions

9.19 × 4.5 × 2.3 cm (3.62 × 1.77 × 0.9")

Weight

158 g (5.57 oz)
