Key Specifications

Inputs/Outputs

System Connection

USB-C (Thunderbolt 4)

Video I/O

Input
1 × BNC (12G-SDI) Female
1 × HDMI 2.0 Female
Output
1 × BNC (12G-SDI) Female (Loop Output)

Audio I/O

No

Format Support

Video Resolution

BNC Input (8/10/12-Bit 4:4:4/4:2:2 RGB and YUV)
4096 × 2160 up to 60 fps
3840 × 2160 up to 60 fps
2048 × 1080p up to 60 fps
1920 × 1080p up to 60 fps
1920 × 1080i up to 59.94 fps
1080 × 720 up to 60 fps
HDMI Input (8/10/12-Bit 4:4:4/4:2:2 RGB and YUV)
4096 × 2160 up to 60 fps
3840 × 2160 up to 60 fps
2048 × 1080p up to 60 fps
1920 × 1080p up to 60 fps
1920 × 1080i up to 59.94 fps
1080 × 720 up to 60 fps

Embedded Audio

HDMI/SDI

Standards

HDR Support

Yes

Broadcast System Compatibility

NTSC, PAL

Hardware

OS Compatibility

Windows 10 to 11 (64-Bit Only)
Linux
macOS 26.0 or Later

Power

Power I/O

1 × USB-C Input

General

Operating Conditions

32 to 104°F / 0 to 40°C up to 90% Humidity

Storage Conditions

-4 to 113°F / -20 to 45°C up to 90% Humidity

Dimensions

5.83 × 2.6 × 1" / 148.08 × 66 × 25.4 mm

Weight

8.11 oz / 229.92 g

Packaging Info

Package Weight

0.72 lb

Box Dimensions (LxWxH)

7.1 × 4.25 × 1.55"
