Key Specifications

Video I/O

Input
1 × BNC (12G-SDI)
Output
1 × BNC (12G-SDI) (Program)
1 × BNC (12G-SDI) (Key)
1 × BNC (12G-SDI) (Fill)

Max Recording Modes

No

IP Video

No

Media/Memory Card Slot

No

Inputs/Outputs

Video I/O

Input
1 × BNC (12G-SDI)
Output
1 × BNC (12G-SDI) (Program)
1 × BNC (12G-SDI) (Key)
1 × BNC (12G-SDI) (Fill)

Other I/O

Input/Output
1 × Thunderbolt 4

Format Support

Internal Recording

No

Standards

HDCP Support

Yes

IP Streaming

IP Video

No

Hardware

Media/Memory Card Slot

No

Wireless

No

Cellular Support

No

General

Operating Conditions

41 to 104°F / 5 to 40°C up to 90% Humidity

Storage Conditions

-4 to 113°F / -20 to 45°C up to 90% Humidity

Dimensions

5.83 × 3.19 × 1" / 148.08 × 81.03 × 25.4 mm

Weight

10.6 oz / 300.5 g

Packaging Info

Package Weight

0.86 lb

Box Dimensions (LxWxH)

7.1 × 4.25 × 1.5"
