Key Specifications

Video I/O

Input/Output: 2x QSFP28 100G Ethernet

Video Resolution

Fiber Input/Output (10-Bit 4:2:2 YUV)
3840 x 2160 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1920 x 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1920 x 1080PsF at 25/29.97/30 fps
1920 x 1080i at 50/59.94/60 fps
1280 x 720 at 50/59.94/60 fps

Audio Format

Unspecified Digital Signal Input/Output: 48 kHz / 24-Bit

Broadcast System Compatibility

NTSC, PAL

Wireless

No

OS Compatibility

macOS 26.0 or Later
Windows 11 or Later

Inputs / Outputs

Video I/O

Input/Output: 2x QSFP28 100G Ethernet

Expansion Slots

No

Format Support

Video Resolution

Fiber Input/Output (10-Bit 4:2:2 YUV)
3840 x 2160 at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1920 x 1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1920 x 1080PsF at 25/29.97/30 fps
1920 x 1080i at 50/59.94/60 fps
1280 x 720 at 50/59.94/60 fps

Audio Format

Unspecified Digital Signal Input/Output: 48 kHz / 24-Bit

Embedded Audio

IP: 16-Channel

Reclocking

No

Standards

Video Standard Compliance

SMPTE ST 2110-20, ST 2110-21, ST 2022-7, ST 2110

HDR Support

Yes

HDMI CEC

No

Broadcast System Compatibility

NTSC, PAL

Hardware

Wireless

No

OS Compatibility

macOS 26.0 or Later
Windows 11 or Later

Display

Display

2.2" LCD

Power

Power I/O

2x IEC C14 Input

PoE Support

No

Power Consumption

100 to 240 VAC

General

Operating Conditions

32 to 104°F / 0 to 40°C up to 90% Humidity

Storage Conditions

-4 to 113°F / -20 to 45°C up to 90% Humidity

Rack Form Factor

1 RU

Certifications

IEEE 1588-2008
SMPTE 2110-20
SMPTE 2110-21
SMPTE 2110-30
SMPTE 2110-40
SMPTE 2022-7

Dimensions

19 x 8.6 x 1.7" / 48.3 x 21.8 x 4.3 cm
