Key Specifications

Main Frame Size

EIA standard 1U

Channels

Dual Channel

Carrier Frequency Range

521.25MHz-936.85MHz

Bandwidth

32MHz

Modulation Mode

FM

Oscillation

PLL synthesized

Frequency Stability

±0.005％(-10℃~50℃)

Sensitivity

S/N>60dB at 25 deviation

Max Deviation Range

±45KHz

Operating Range

80M typical(in open space)

Audio Performance

Frequency Response

80Hz-18KHz ±3dB

S/N

>105dB

T.H.D.

<0.7％@1KHz

Power Supply

Power Supply

DC 12V/12W

Dimensions & Weight

Dimension(mm)

410(W)x206(D)x43(H)

Weight

Approximately 1.9kg
