Key Specifications

Panel Type

TFT LCD

Display Size

7.0" / 17.8 cm

Screen Resolution

1920 x 1200

Image Controls

False Color, Focus Assist, Focus Peaking, Screen Markers

Inputs/Outputs

1x USB-C Video Input
1x Barrel Power Input

Display

Panel Type

TFT LCD

Display Size

7.0" / 17.8 cm

Screen Resolution

1920 x 1200

Aspect Ratio

16:10

Touchscreen

Yes

Maximum Brightness

2000 nits / cd/m2

Pixels Per Inch (ppi)

323 ppi

Image Controls

False Color, Focus Assist, Focus Peaking, Screen Markers

Inputs / Outputs

Inputs/Outputs

1x USB-C Video Input
1x Barrel Power Input

Video Format

USB (10-Bit 4:2:2 YUV)
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50

Input Power

12 VDC

General

Operating Conditions

32 to 104°F / 0 to 40°C up to 90% Humidity

Storage Conditions

-4 to 140°F / -20 to 60°C up to 90% Humidity

Tripod/Accessory Mounting

Bottom/Bracket
1x V-Lock

Dimensions

11.97 x 9.17" / 30.4 x 23.29 cm (Including Bracket)

Weight

5.27 lb / 2.39 kg
