Key Specifications

Channels of I/O

6 Inputs / 4 Outputs

Maximum Sampling Rate

192 kHz / 32-Bit

Number of Microphone Inputs

4

Analog Audio I/O

4x Combo XLR-1/4" TRS Mic/Line/Hi-Z Input, 1x 3.5mm TRS Mic/Line Input, 1x 3.5mm TRS Aux Input, 1x 3.5mm TRS Headset Input, 2x 1/4" TRS Line Output, 2x 1/4" TRS Headphone Output, 2x 1/4" TRS Main Output

Digital Audio I/O

No

Host Connection

2x USB-C

Power Requirements

USB Bus Power

General

Display

4.3" Color LCD Touchscreen

Channels of I/O

6 Inputs / 4 Outputs

Built-In DSP

Yes

Maximum Sampling Rate

192 kHz / 32-Bit

Number of Microphone Inputs

4

Built-In Microphone

No

Input Level Adjustment

Knob

Signal Processing

Pad

No

Gain/Trim Range

78 dB

Connectivity

Analog Audio I/O

4x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line/Hi-Z Input, 1x 3.5mm TRS Mic/Line Input, 1x 3.5mm TRS Aux Input, 1x 3.5mm TRS Headset Input, 2x 1/4" TRS Line Output, 2x 1/4" TRS Headphone Output, 2x 1/4" TRS Main Output

Phantom Power

48 V

Digital Audio I/O

No

Host Connection / USB

2x USB-C

Host Connection Protocol

Not Specified by Manufacturer

USB (Non-Host)

No

Sync I/O

No

Network I/O

No

MIDI I/O

No

Expansion Slots

No

Wireless

No

Performance

Frequency Response

20 Hz to 20 kHz

Headphone Output Power

100 mW per Channel into 40 Ohms

Dynamic Range

Combo XLR-1/4" Mic/Line/Hi-Z Inputs: 115 dB; 1/4" Line Outputs: 125 dB

THD

Combo XLR-1/4" Line/Mic/Hi-Z Inputs: 0.0008%; 1/4" Line Outputs: 0.00036%

EIN

-128 dBA

Digital Audio

Sample Rates

Up to 192 kHz

Bit Depths

32-Bit

Sync Sources

No

Audio Storage & Playback

Media/Memory Card Slot

Single Slot: microSD/microSDHC

Compatibility

OS Compatibility

Windows / macOS

Required Hardware

USB Cable

Power

Power Requirements

USB Bus Power

Power Consumption

15 W (Typical), 0.1 W (Idle)

Physical

Operating Conditions

32 to 104°F / 0 to 40°C

Storage Conditions

-4 to 140°F / -20 to 60°C

Dimensions

9.6 x 7.2 x 3.1" / 24.4 x 18.3 x 7.9 cm

Weight

4.2 lb / 1.9 kg

Packaging Info

Package Weight

6.35 lb

Box Dimensions (L × W × H)

14.8 x 9.5 x 5.6"
