Key Specifications

Illuminance Measurement

Resolution

0 ~ 99.99 lx (0.01 lx)
99.99 fc (0.01 fc)

100 ~ 999.9 lx (0.1 lx)
999.9 fc (0.1 fc)

1000 ~ 400000 lx (1 lx)
37160 fc (1 fc)

Accuracy

±3% (calibrated under standard light source at 2856K)
±6% (calibrated under other visual light sources)

Unit Switch

lx / fc (1 fc = 10.764 lx)

Measurement Functions

Auto Range

Yes

MAX / MIN / AVG

Yes

Data Hold

Yes

Color Correction Coefficient (CCF)

Yes

Over-range Indication

OL Display

Low Battery Indication

Auto power off when low battery icon flashes for 10 seconds

Auto Power Off

Yes (cancelable, triggers if idle for 10 seconds)

Connectivity & Data

Bluetooth / APP

Yes

Data Record

99 sets

Record Interval

1 ~ 59 seconds

Real-time Sync

Time auto-updated via manual setting or mobile APP connection

Probe & Design

Probe Type

Integrated (rotatable) / Split design

General Characteristics

Power Supply

3 × AAA 1.5V batteries

Battery Life

Over 100 hours (Bluetooth and backlight off, alkaline batteries)

Working Temperature

-10°C ~ 50°C

Storage Temperature

-20°C ~ 70°C

Humidity

Working: < 90% RH (non-condensing)
Storage: < 80% RH (non-condensing)

Weight

Approx. 257 g (excluding batteries)

Product Size

235 × 64.5 × 39.8 mm

Standard Accessories

Quick start guide, 3 × AAA batteries, strap, safety instructions, gift box

Standard Quantity per Carton

5 pcs

Carton Size

395 × 290 × 160 mm
