Key Specifications

Number of Channels

2

Amplifier Power Rating

2×160 W

Load Impedance / Voltage

70 / 100 V

DSP

24-Bit DSP

Performance

Frequency Response

20 Hz to 20 kHz

I/O Impedance

Line Input: 20 Kilohm
Page Input: 2 Ohms

Input Level

Line: 4 dBu (Nominal)
Page: -38 dBu (Nominal)

Input Gain/Trim Range

Line Input: -8 dBu to +22 dBu
Page Input: -58 dBu to +12 dBu

VCA Control

Yes

Dynamic Range

88 dB

THD+N

< 0.5%

Crosstalk

≤ -58 dBu (at 1 kHz)

Signal Processing

Sample Rate

Up to 48 kHz

AD/DA Conversion

24-Bit

DSP

24-Bit DSP

Audio Delay

No

EQ

Yes

Ducking/Muting

No

Limiting

No

Connectivity

Audio I/O

2× Stereo RCA Coaxial Unbalanced Line Input
2× Block 5-Pin Balanced Line Input
1× Block 4-Pin Balanced Line/Mic Input
1× Stereo RCA Unbalanced Line Output
2× Block 2-Pin Speaker Output

Digital Audio I/O

No

Network I/O

No

USB I/O

No

Wireless

Bluetooth 5.0

Power

AC Input Power

100 to 240 VAC, 50 / 60 Hz

AC Power Connector

1× IEC

AC Outlet

Yes

Physical

Display & Indicators

1× OLED

Rackmount Size

1 U

Cooling

Fan

Dimensions

19.0 × 1.7 × 12.8" / 483 × 44 × 324 mm

Weight

9.7 lb / 4.4 kg
