Key Specifications

Inputs / Outputs

3 x XLR In / 6 x XLR Out

Digital Resolution

24-bit / 96 kHz AD/DA

Internal Processing

40-bit Digital Signal Processing (DSP)

Frequency Response

20 Hz – 20 kHz

Signal to Noise Ratio

>115 dB

Input Processing

Gate, 31-Band GEQ, 8-Band PEQ, Delay, Phase, HPF/LPF

Output Processing

Crossover, 5-Band PEQ, Compressor/Limiter, Delay, Phase

Connectivity & Control

Data Connections

Ethernet, USB, RS232, RS485

System Linking

Up to 255 units via RS485

Presets

20 User Presets (Password Protected)

Physical Specifications

Display

20 x 2 LCD & 5-Segment LED Meters

Dimensions (Rack)

45 x 480 mm (1U Standard Rack Mount)

Net Weight

2.62 kg
