Key Specifications

Speaker Configuration

System Type

Single 18" Active Subwoofer

Low Frequency Driver

1 × 18" Driver (100 mm / 4" Voice Coil) Ferrite Magnet

Performance

Frequency Response

30 Hz – 150 Hz

Sensitivity

102 dB

Maximum SPL

128 dB

Nominal Impedance

4 Ω

Power Rating

900 W

Amplifier

Class D with DSP

Crossover Frequency

80 Hz – 250 Hz

Connectivity

Input Connectors

2 × XLR Male

Output Connectors

2 × XLR Female

LED Indicators

Power, Signal, Clip

Power

AC Input

AC 220 V, 50/60 Hz

AC Connectors

PowerCON Blue / White

Construction

Cabinet Material

Plywood

Finish

Polyuria Paint (Waterproof)

Dimensions & Weight

Item Dimensions (L × W × H)

610 × 750 × 510 mm (61 × 75 × 51 cm)

Net Weight

53 kg

Carton Dimensions (L × W × H)

740 × 825 × 760 mm (74 × 82.5 × 76 cm)

Gross Weight

86.5 kg
