Key Specifications

Speaker Configuration

System Type

Single 12" 2-Way Active Line Array Speaker System

Low Frequency Driver

1 × 12" Mid-Bass Driver (75 mm Voice Coil)

High Frequency Driver

3 × 34 mm Voice Coil PEEK Diaphragm Drivers with Neodymium Magnet

Performance

Frequency Response

60 Hz – 20 kHz

Sensitivity

98 dB

Maximum SPL

122 dB

Nominal Impedance

8 Ω

Power Rating

700 W

Amplifier

Class D with DSP

Coverage Angle

100° × 15°

Crossover Frequency

2.5 kHz

Connectivity

Input Connectors

2 × XLR Male

Output Connectors

2 × XLR Female

LED Indicators

Power, Signal, Clip

Power

AC Input

AC 90 – 260 V

AC Connectors

PowerCON Blue / White

Construction

Cabinet Material

Plywood

Finish

Polyuria Paint (Waterproof)

Dimensions & Weight

Item Dimensions (L × W × H)

635 × 450 × 350 mm (63.5 × 45 × 35 cm)

Net Weight

27.2 kg

Carton Dimensions (L × W × H)

740 × 540 × 975 mm (74 × 54 × 97.5 cm)

Gross Weight

88.5 kg
