Key Specifications

Speaker

• Speaker Type: Active Line Array Loudspeaker
• Configuration: 2-Way
• Enclosure Type: Bass-Reflex
• Total Output Power: 875 W RMS / 1750 W Peak
• Amplifier Power Rating: Low Frequency (LF): 750 W RMS, Mid Frequency (MF): 125 W RMS
• Amplifier Class: Class-D

Drivers

• LF Driver: 1x 12" / 30.5 cm Woofer, Voice Coil: Dual, Magnet: Neodymium
• HF Driver: 3x 1.5" / 38.1 mm Horn-Loaded Compression Driver, Magnet: Neodymium

Performance

• Frequency Range/Response: 57 Hz to 20 kHz (-10 dB), 75 Hz to 20 kHz (±3 dB)
• Maximum SPL: 136 dB
• Coverage Angle: 100° H x 15° V

Signal Processing

• EQ & Filters: No
• Alignment Delay: No
• Digital Signal Processing: No

Connectivity

• Audio I/O: 1x XLR 3-Pin Line Input, 1x XLR 3-Pin Line Thru
• Network I/O: No
• USB I/O: No
• Wireless: No
• Mobile App Compatible: No

Power

• AC Input Power: 120 to 240 VAC, 50 / 60 Hz
• AC Power I/O: 1x powerCON Input, 1x powerCON Output
• Current Consumption: 120 VAC: 6 A (Max), 240 VAC: 3 A (Max)

Physical

• Color: Black
• Mounting: Stand Mount, 1x 1.42" / 36 mm Dual-Angle Pole Socket (Bottom), 2x Fly Point - Unspecified Thread
• Construction Material: Plywood
• Environmental Resistance: No
• Dimensions: 13.8 x 23.5 x 17.5" / 34.9 x 59.7 x 44.4 cm
• Weight: 52 lb / 24 kg

Packaging Info

• Package Weight: 63.4 lb
• Box Dimensions (L x W x H): 26 x 21.5 x 18"
