Key Specifications

Video Input

Interface

1 x HDB-15 Male (Blue)

Impedance

75 Ohms

Max Distance

5.9' / 1.8 m

Video Output

Interface

4 x HDB-15 Female (Blue)

Impedance

75 Ohms

Video

Bandwidth

450 MHz (Maximum)

Resolution

Up to 1920 x 1440

Max Distance

98.4' / 30.0 m

Audio

Input

1 x Mini Stereo Jack Female (Green)

Output

4 x Mini Stereo Jack Female (Green)

Control

RS-232

1 x DB-9 Female (Black)

General Specifications

EDID

EDID Mode: Port 1 / Audio / Default

Power

Connector: 1 x DC Jack
Consumption: 5.3 VDC, 1.2 W

Operating Temperature

32 to 122°F / 0 to 50°C

Storage Temperature

-4 to 140°F / -20 to 60°C

Humidity (Non-Condensing)

0–80% RH

Dimensions

7.9 x 3.0 x 1.7" / 20.0 x 7.6 x 4.4 cm

Weight

1.50 lb / 0.68 kg

Packaging Info

Package Weight

2.2 lb

Box Dimensions (L × W × H)

11.2 x 6.9 x 2.6"
