Key Specifications

Input

Video Inputs

4 × BNC (3G-SDI), 2 × HDMI (2.0), 2 × DVI-I DL (DVI/VGA)

Input Video Format

SDI: 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps, 1080i at 50/59.94/60 fps, 1080PsF at 23.98/24/25/29.97/30 fps, 720p at 23.98/24/25/30/50/59.94/60 fps, 576i / 625 lines at 50 fps, 480i / 525 lines at 59.94 fps

HDMI: UHD 4K at 30/50/60 fps, DCI 2K at 30/50/60 fps, 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps, 1080i at 50/59.94/60 fps, 720p at 23.98/24/25/29.97/30/50/59.94/60 fps, 576p at 50 fps, 576i / 625 lines at 50 fps

Audio Inputs

2 × XLR 3-Pin Analog, 2 × RCA Analog

Output

Video Outputs

2 × BNC (3G-SDI) (Program), 2 × HDMI (Program), 1 × USB-C (Program)

Output Video Format

HDMI / SDI / USB-C: 1080p at 24/25/30/50/60 fps

Audio Outputs

2 × RCA Analog, 1 × 3.5 mm TRS

Multiview Output

8-Way Multiview via SDI, 8-Way Multiview via HDMI

Connectivity

Other I/O

2 × USB-A Input, 1 × RJ45 LAN Input, 1 × DE-9/DB-9 RS-422, 1 × DE-15/DB-15 Tally

Video Standard Compliance

SMPTE 259M / 292M / 424M

Hardware

OS Compatibility

Windows 7 or Later, macOS, Linux

Wireless

No

Power

Power I/O

1 × Barrel Connector (12 VDC at 1.8 A) Input

Power Consumption

22 W

General

Dimensions

13.4 × 10.2 × 2.8" / 34 × 26 × 7 cm

Weight

6.6 lb / 3 kg

Packaging Information

Package Weight

7.6 lb

Box Dimensions

15.1 × 14.7 × 5.1"
