Key Specifications

LED Indicators

Input LEDs

3 x HDMI-In (Green)

Power LED

1 x Power LED (Green)

Pushbuttons

Select Button

1 x Push Button (Input Selection)

Audio

Audio Input

3 x HDMI Type A Female (Black)

Audio Output

1 x HDMI Type A Female (Black)

Video Input

Interfaces

3 x HDMI Type A Female (Black)

Impedance

100 Ω

Maximum Distance

Max 5m @ Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)

Video Output

Interfaces

1 x HDMI Type A Female (Black)

Impedance

100 Ω

Maximum Distance

Max 5m @ Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)

Video

Maximum Data Rate

18 Gbps (6 Gbps Per Lane)

Maximum Pixel Clock

600 MHz

Compliance

HDMI 2.0 (3D, Deep Color, 4K, HDR10, Dolby Vision)
HDCP 2.2

Maximum Resolution

4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)

Control

IR

1 x Mini Stereo Jack Female (Black) / Max distance @ 5m

Connectors

Power Connector

1 x DC Jack

Power Note

ATEN strongly recommends using the supplied USB to DC cable and a 5V/0.5A power adapter as the main power source.
Power supplied from the HDMI connection may be insufficient for full operation.

Power

Power Consumption

DC5V:1.46W:6BTU/h

Power Consumption Note

The measurement in Watts indicates the typical power consumption of the device with no external loading.
The measurement in BTU/h indicates the power consumption of the device when fully loaded.

Environmental

Operating Temperature

0-40 °C

Storage Temperature

-20 - 60 °C

Humidity

0 - 80% RH, Non-Condensing

Physical Properties

Housing

Metal

Weight

0.15 kg (0.33 lb)

Dimensions (L x W x H)

7.16 x 7.90 x 2.55 cm
(2.82 x 3.11 x 1 in.)

Carton Lot

20 pcs

Additional Note

For some rack mount products, standard physical dimensions of WxDxH are expressed using an LxWxH format.
