Key Specifications

Acoustical Specifications

Frequency Response (-3 dB)

55 Hz–18 kHz

Max SPL @ 1 m

114 dB / 120 dB (Peak)

Dispersion (H × V)

90° × 60°

Transducers

Compression Driver

1 × 1" HF

Woofer

1 × 10" LF

Input / Output Section

Input Signal

100 Hz HP with Sub, Mixer IN/OUT, Stereo/Mono out, 3.5 mm Aux in, BT streaming

Input Connectors

2 × XLR, 2 × 1/4", 1/8", Bluetooth and Main in (XLR)

Processor Section

Crossover Frequencies

1.6 kHz

Power Section

Total Power

250 W (RMS); 500 W (MUSIC); 1000 W (PEAK)

Nominal Impedance

8 Ω

Cooling

Speed controlled fan

Voltage Range

AC 110V/230V, 50Hz/60Hz

Physical Specifications

Cabinet / Case Material

Polypropylene Cabinet, ABS Baffle, Metal Grille

Handles

2 × Plastic Handles (1 × Side / 1 × Back)

Grille

Powder Coated Steel with Grille Cloth

Color

Black

Size

Dimensions (W × D × H)

337 × 290 × 528 mm (13.3 × 11.4 × 20.8 in)

Package Dimensions (W × D × H)

400 × 350 × 585 mm (15.7 × 13.8 × 23 in)

Weight

Net Weight

12.6 kg (27.8 lb)

Gross Weight

15.5 kg (34.2 lb)
