Key Specifications

Electrical Parameters

Power Connector

100–240V~, 1.6A, 50/60Hz

Rated Power Consumption

28 W

Operating Environment

Operating Temperature

0°C to 45°C

Operating Humidity

20% RH to 90% RH, non-condensing

Storage Environment

Storage Temperature

-20°C to +70°C

Storage Humidity

10% RH to 95% RH, non-condensing

Physical Specifications

Dimensions

483.6 × 301.2 × 50.1 mm

Net Weight

4 kg

Noise Level

45 dB(A) (Typical at 25°C / 77°F)

Packing Information

Accessories Included

1 × Power Cord
1 × HDMI to DVI Cable
1 × USB Cable
1 × Ethernet Cable
1 × HDMI Cable
1 × Quick Start Guide
1 × Certificate of Approval
1 × Safety Manual

Packing Size

550 × 175 × 400 mm

Gross Weight

6.8 kg

Video Source Features

HDMI 1.3 Input

8-bit RGB 4:4:4
Max Input Resolution: 1920 × 1200 @ 60Hz (Standard)
3840 × 648 @ 60Hz (Custom)
600 × 3840 @ 60Hz (Forced)

DVI Input

8-bit RGB 4:4:4
Max Input Resolution: 1920 × 1200 @ 60Hz (Standard)
3840 × 648 @ 60Hz (Custom)
600 × 3840 @ 60Hz (Forced)

OPT 1 Input

8-bit RGB 4:4:4
Max Input Resolution: 1920 × 1200 @ 60Hz (Standard)
3840 × 648 @ 60Hz (Custom)
600 × 3840 @ 60Hz (Forced)

Supported Color Formats

RGB 4:4:4
YCbCr 4:4:4
YCbCr 4:2:2

Unsupported Formats

YCbCr 4:2:0
10-bit Color
12-bit Color

3G-SDI Input

Max Input Resolution: 1920 × 1080 @ 60Hz
Supports ST-424 (3G), ST-292 (HD), and ST-259 (SD) video standards
Input resolution and bit depth settings are not supported
