Key Specifications

Speaker Type

Full-Range, Powered Speaker, Bass-Reflex

Frequency Response

80 Hz to 20 kHz

Nominal Coverage Angle

Horizontal: 170°
Vertical: 25° (+12.5° to -12.5°)

Effective Coverage

Horizontal: 180°
Vertical: 30° (+15° to -15°)

Components

16 × 1.5" (3.75 cm) Cone Drivers

Maximum Output Level

102 dB SPL (using PoE+, IEEE 802.3at)

Amplifier & Power

Power Rating

Dynamic: 15 W (PoE+, IEEE 802.3at), 6 W (PoE, IEEE 802.3af)
Continuous: 15 W (PoE+, IEEE 802.3at), 6 W (PoE, IEEE 802.3af)

Power Requirements

PoE+ (IEEE 802.3at), PoE (IEEE 802.3af)

Power Consumption

Idle: 3 W with 1/8 Pink Noise
6 W with PoE+ (IEEE 802.3at)
4.3 W with PoE (IEEE 802.3af)

I/O Connector

1 × RJ45 (Dante)

Protection & Cooling

Protection Circuits

Speaker Processing: Clip Limiting, Integral Power Protection
Amplifier: Overcurrent, Over-Temperature, Undervoltage Lock Out, DC Detection, Clock Detection
Power Supply: Overload, Overvoltage, Undervoltage Lock Out

Cooling

Natural Convection

Physical

Finish / Grille Color

Black Painting (Approx. Munsell N3.0)

Magnetic Shielding

No

Dust & Water Resistant

No

Dimensions (W × H × D)

2.1 × 44.1 × 4.1" / 54 × 1120 × 104 mm

Weight

11 lb / 5 kg

Packaging Information

Package Weight

15.82 lb

Box Dimensions (L × W × H)

48.5 × 9 × 6.25"
