Key Specifications

System Type

Wireless Discussion / Conference System Host Controller

Signal Coverage Range

60 m Radius

Power Supply Input

DC 12V – 15V (≤ 1A)

Power Consumption

7 W Rating

Audio Channel Specifications

Transmission Method & Modulation

UHF Wireless One-Way (FM Modulation)

Audio Channels

5 Channels (1 Chairman, 4 Delegate)

Carrier Frequency Band

626 MHz to 658 MHz

Receiving Sensitivity

-100 dBm

Audio Gain

≤ 20 dB

Frequency Response

50 Hz to 15 kHz (50 – 15000 Hz)

Signal-to-Noise Ratio (S/N)

>85 dB

Total Harmonic Distortion (THD)

<0.8%

Data Control Channel Specifications

Transmission Method & Modulation

Wireless Two-Way (FSK Modulation)

Data Channels

16 Channels

Frequency Range

433.4 MHz to 434.4 MHz

Sensitivity & Frequency Deviation

Sensitivity: -100 dBm | Frequency Deviation: <0.002%

Transmission Power & Communication Rate

Transmission Consumption: ≤ 6 dBm | Rate: 100 kbps

Environmental & Physical Specifications

Operating Temperature Range

-10°C to +40°C

Item Dimensions (H×L×W)

85mm x 485mm x 355mm (3.35" x 19.09" x 13.98")

Item Weight

7.0 kg (7000 g / 15.43 lbs)
