Key Specifications

Wireless Transmission

Digital 2.4 GHz

Included Transmitters

2 × Bodypack with Microphone

Diversity

Non-Diversity

Maximum Operating Range

656.2 ft / 200 m

Maximum Systems per Setup

4

Latency

3.5 to 4 ms

Encryption

128-Bit

Receiver

Form Factor

Beltpack

Mounting Options

Belt Clip (with Included Hardware)

Antenna

1 × Internal

Number of Audio Channels

2

Audio I/O

1 × 1/8" / 3.5 mm TRS Female Unbalanced Mic Output

Gain Range

-24 to 0 dB (12 dB Steps)

USB Connectivity

1 × USB Type-C (Audio, Bus Power, Charging)

Power Requirements

Battery or Bus Power (USB)

Battery Type

1 × Built-In Rechargeable (Included)

Battery Charging Time

2 Hours

Approx. Battery Life

7 Hours

Display & Indicators

Graphic LCD (AF Level, Battery Status, Metering, RF Level, Transmitter Battery Status)

Dimensions

1.7 × 1.8 × 0.7" / 4.4 × 4.5 × 1.8 cm

Weight

1.1 oz / 32 g

Transmitter

Form Factor

Bodypack with Microphone

Audio I/O

1 × 1/8" / 3.5 mm TRS Female Unbalanced Input

Muting

On/Off Switch

Audio Input Level

-20 dBV (Max)

Auto-Level Control

No

Gain Range

+20 dB

Signal Processing

None

Sync Method

Proprietary

Antenna

1 × Internal

Power Requirements

Battery or Bus Power (USB)

Battery Charging Time

2 Hours

Approx. Battery Life

7 Hours

USB Connectivity

1 × USB Type-C (Bus Power, Charging)

Indicators

LED (Sync), LED (Battery Status)

Dimensions

1.7 × 1.8 × 0.7" / 4.4 × 4.5 × 1.8 cm

Weight

1.1 oz / 30 g

Microphone

Form Factor

Integrated

Sound Field

Mono

Operating Principle

Pressure Operated

Capsule

Electret Condenser

Polar Pattern

Omnidirectional

Frequency Range

50 Hz to 20 kHz

Equivalent Noise Level

22 dB (A-Weighted)

Maximum SPL

100 dB SPL

Packaging Information

Package Weight

0.52 lb

Box Dimensions (L × W × H)

6 × 3 × 2"
