Key Specifications

Amplifier Class

Class D

Output Power (EIAJ 8:32 All Channels Driven)

4 x 4000 W @ 2.7 Ω
4 x 2600 W @ 4 Ω
4 x 1400 W @ 8 Ω

Frequency Response (-3 dB)

20 Hz - 23,000 Hz

SNR Analog Inputs (Unweighted)

>111 dB

SNR Digital Inputs (Unweighted)

>115 dB

Crosstalk

<70 dB

Distortion (THD+N)

<0.2% (20 Hz - 20 kHz, 1000 W @ 4 Ω)

Gain (Linear Mode @ 0 dB)

32 dB

Damping Factor (@ 4 Ω, 20 Hz - 1500 Hz)

>95

Max Burst Length

200 ms (@ 50 Hz, CF = 7 dB, 4 Ω, 1% THD+N)

Input Section

Total Number of Inputs

8

Line Inputs

4

Line Connectors

XLR

Digital Inputs

4

Digital Connectors

XLR

Digital Type

AES/EBU

General Purpose Inputs (GPI)

2

Programmable GPI

Yes

Photo-Coupled GPI

2

Output Section

Signal Outputs

4

Signal Output Connectors

XLR

Power Output Connectors

Speakon

General Purpose Outputs (GPO)

3

Programmable GPO

Yes

Processing

DSP

2 SHARC, 40-bit Floating Point, 96 kHz
2 ADAU, 32-bit Fixed Point, 96 kHz

EQ Filters

Peaking, HI/LO-Shelving, HI/LO-Pass (Butterworth, Linkwitz-Riley, Bessel)

Advanced Algorithms

FiRPHASE Technology, BASS Shaper, Air Compensation, Mid-Low Correction, Driver Excursion Control, Dynamic PEQ, Multi-Band Compressor, Pilot Tone Detection, Backup Recovery Strategy, Impedance Load Measurement

Compressors

RMS Limiter, Dynamic Compressor, Power Limiter, Thermal Compressor

Delay

0 to 4000 ms (Each Channel)

Tone Controls

Yes

High-Pass Filter

10 Hz - 1000 Hz

Crossover

2500 - 3500 Hz

Automatic Gain Control

Yes

Configuration and Control

Configuration

Front Panel Touch Screen, PC Software

Network

Gigabit Ethernet

RCF Speaker Presets

Yes

Priority

Yes

RDNet

Onboard

Protections

Cooling

Forced

Short Circuit Protection

Yes

Thermal Protection

Yes

DC Protection

Yes

Fuses

Yes

VHF Protection

Yes

Operating Conditions

Temperature Range (Continuous Operation)

-5°C to +40°C / +23°F to +104°F

Temperature Range (Reduced Output Power)

-5°C to +50°C / +23°F to +122°F

Fan Noise Idle

<35 dBA

Fan Noise Max

<64 dBA

Power Requirements

Operating Voltage

100-240 V~, 50/60 Hz

Nominal Current AC @ 100-120 V

30 A

Nominal Current AC @ 220-240 V

16 A

Standby Power Consumption

20 W

Idle Power Consumption

90 W

Maximum Power Consumption

5800 W

Main Fuse

Internal

Standard Compliance

Safety Agency

CE Compliant, UL 62368-1 3rd Edition, CSA C22.2 No. 62368-1:19 3rd Edition

Physical Specifications

Cabinet / Case Material

Metal

Handles

2 Metal Handles for Rack Mount

Color

Black (RAL 9005)

Rack Mounting

19", 2U

Size / Weight

Height

88.7 mm / 3.49"

Width

482 mm / 18.98"

Depth

482.4 mm / 18.99"

Weight

15 kg / 33.07 lb
