Key Specifications

Mixer Architecture

19 Analog Input Channels (16 Mono / 3 Stereo) | 16 Mic Preamps | Max I/O: 22x Input / 10x Output

Mix Routing

Main Mix / FX Bus

Faders & Controls

16x 100mm (3.9") Channel Faders, 1x 100mm (3.9") FX Fader

Metering

Main: 2x 12-Segment LED | Channels: Single LED per channel

Channel Controls

Mute and PFL per Input Channel & FX Bus

Rack Mountable

No

Audio Channels & Performance Specifications

Frequency Response

Mic Input to Main Output: 20 Hz to 20 kHz (+0.5/-1 dB @ 30dB Gain)
Line Input to Main Output: 10 Hz to 30 kHz (+0.5/-1 dB @ Unity Gain)
Stereo Input to Main Output: 10 Hz to 30 kHz (+0.5/-1 dB)

THD+N

Mic Input: 0.004% @ Unity Gain | Line Input: 0.005% @ Unity Gain | Stereo Line Input: 0.003% @ Unity Gain

Noise Floor

Main Output: -84 dBu (Master Level at Unity, 22 Hz to 22 kHz)

Gain / Trim Range

Mic Input: -6 to +63 dB | Line Input: -10 to +26 dB | Stereo Input / Return / Fader / Aux: -∞ to +10 dB | Matrix: -∞ to +6 dB

Max Input Levels

Mic Input: +17 dBu | Line Input (Mono): +30 dBu | Insert Return: +21 dBu

Digital Audio

16-Bit | Sample Rates: 32 / 44.1 / 48 kHz

Signal Processing & Effects

Equalization

3-Band EQ
Mono Channels: High ±15 dB @ 12 kHz, Mid ±15 dB @ 120 Hz - 4 kHz, Low ±15 dB @ 80 Hz
Stereo Channels: High ±15 dB @ 12 kHz, Low ±15 dB @ 80 Hz

Filters

High-Pass Filter (100 Hz, 12 dB/Octave)

Built-In Effects

Yes (No Graphic EQ, No Dynamic Processing)

Connectivity & Interfaces

Analog Inputs

16x XLR 3-Pin Balanced Mic Inputs (+48V Phantom Power, Global)
16x 1/4" TRS Balanced/Unbalanced Line Inputs
6x 1/4" TRS Balanced/Unbalanced Line Inputs (3 Stereo Pairs)
2x 1/4" TRS Balanced Aux Return (1 Stereo Pair)
1x Stereo RCA Coaxial Unbalanced Line/Aux Input, 1x Stereo RCA 2-Track Input
16x 1/4" TRS Unbalanced Channel Inserts, 2x 1/4" TRS Unbalanced Main Inserts
1x 1/4" TS Footswitch Input

Analog Outputs

2x XLR 3-Pin Balanced Main Output (1 Stereo Pair)
1x 1/4" TRS Balanced Main Output (Mono)
1x Stereo RCA Coaxial 2-Track Output
1x Stereo RCA Coaxial Unbalanced Alt Output
3x 1/4" TRS Balanced Mono Aux Sends

Headphone Outputs

1x 1/4" TRS Headphone Output, 1x 1/8" (3.5 mm) TRS Headphone Output

USB & Digital I/O

1x USB-B 1.1 (2 In / 2 Out Interface) | OS: Windows / macOS
(No MIDI, No Digital I/O, No Wireless)

Power Specifications

AC Input Power

100 to 240 VAC, 50 / 60 Hz (Power supply included)

Dimensions, Weight & Packaging

Item Dimensions (H×W×D)

98mm x 645mm x 465mm (3.9" x 25.4" x 18.3")

Item Weight

10.5kg (23.1 lbs)

Box / Package Dimensions (L×W×H)

774.7mm x 622.3mm x 254.0mm (30.5" x 24.5" x 10.0")

Package Weight

12.7kg (28.0 lbs)
