Key Specifications

Audio Processing & Effects

Simultaneous Effects

Up to 7 (6 standard effects + 1 pedal effect)

Preloaded Patches

250 presets

User Patches

Up to 300 saveable patch memories

Built-in Models

79 traditional and boutique effects, and 22 Amp/Cabinet models

A/D Conversion

24-bit, 128x oversampling

D/A Conversion

24-bit, 128x oversampling

Signal Processing

32-bit

Frequency Response

20 Hz – 20 kHz (+0.5 dB / −0.5 dB, 10k Ω load)

Hardware & Controls

Expression Pedal

Included (controls Volume, Pitch, Wah, etc.)

Footswitches

4 footswitches (Cross key navigation)

Encoders/Knobs

4 rotary encoders for parameter tweaking

Display

256 × 128 dot-matrix LCD

Connections

Inputs

Input: Standard mono phone jack (Rated level: −20 dBu / Impedance: 470 kΩ)
Aux In: Stereo mini jack (Rated level: −10 dBu / Impedance: 10 kΩ)

Outputs

Output (L/R): Standard mono phone jack (Max output level: +9.3 dBu)
Phones: Stereo mini jack (Max output power: 20 mW + 20 mW into 32 Ω load)

USB & Interface Capabilities

USB Port

USB 2.0 Type-C port (requires a cable that supports data transfer)

Audio Interface

2-in / 2-out USB audio interface (44.1 kHz, 32-bit)

Software Support

Compatible with Handy Guitar Lab (iOS/Android) and Guitar Lab (PC/Mac)

Power

Power Source

9V DC, 500 mA (center-negative, ZOOM AD-16 power supply)

Bus Power

Fully supported via USB
