Key Specifications

Product Model

Active ZP-12A

System Type

2-Way 12" Active Vented Loudspeaker

Amplifier Power

1000W Continuous RMS (650W LF + 350W HF) | 4000W Peak

Max SPL @ 1m

128 dB Continuous / 131 dB Peak

Acoustic Performance

Frequency Response

53 Hz – 20 kHz (-3 dB)

Transducers

12" Woofer (LF) | 1" Throat Compression Driver (HF)

Horn Coverage

90° Horizontal x 60° Vertical

Crossover Frequency

2.0 kHz

Connectivity & DSP

DSP Preset Modes

LIVE, MUSIC, SPEECH, MONITOR

Inputs

2 x XLR/TRS Combo, 3.5mm Aux, Bluetooth Stereo

Indicators

Signal/Clip Limiter, DSP Mode, BT Pair/Link, Power

Physical & Installation

Enclosure

Trapezoidal Polypropylene, Perforated Steel Grille

Mounting

36mm Pole-mount, Integrated M10 Points

Dimensions (HxWxD)

615 x 364 x 348 mm (24.2" x 14.3" x 13.7")

Weight

16.3 kg (35.9 lbs)
